Lens Lab Optics' 10nm stepping piezo stage features an aluminum alloy body and stainless steel cross roller bearings, delivering high precision, repeatability, and linearity. Its ultra-thin and compact structural design facilitates easy mechanical integration. Lens Lab Optics offers stocked piezo stage products with a minimum step size of 10nm for your selection.

Lens Lab Optics aims to provide you with a simple, economical, and efficient solution during the construction of your optical experimental system. Our products are designed to allow for quick fixing, replacement, and adjustment of components during use.

Product Features

1. Driven by a piezoelectric ultrasonic motor with an axial thrust of 8 N

2. Equipped with stainless steel cross roller bearings, offering high precision, repeatability, and linearity

3. Power-off self-locking with built-in braking function and zero backlash

4. Minimum step size of 10 nm

5. Grating scale position sensor

6. Ultra-thin and compact design for easy mechanical integration; aluminum alloy body with anodized finish

Specifications

Table Size: 100 × 155 mm                                   Stroke: 90 mm

Motor Model: M304                                              Axial Thrust: 8 N

Maximum Load: 5 kg                                            Maximum Speed: 20 mm/s

Minimum Step Size: 10 nm                                  Repeatability: 0.3 μm

Position Sensor: Grating or Magnetic Scale        Straightness: <2 μm

Running Parallelism: <10 μm                               Material: Aluminum Alloy, Anodized
